Mainly used in emergency lights, battery protection, LED drive power, adapters, LCD displays, low-power medical equipment
Time - current features:Time-Lag (T)
Breaking Capacity: 535A@150/250VAC,50A@150/250VAC
Standard:UL248-14
Approvals: cULus、cURus、TUV、CQC、PSE、KC
Materials:shell-ceramic tube, metal cap-nickel-plated brass, lead cap-nickel-plated cap, tin-plated copper wire
Operating Temperature:-55℃ to +125℃
Soldering Parameters:260℃.≤5 sec (Wave Soldering),350℃.≤3 sec (Hand Soldering)
Soldering Peak:260℃. 10 sec.,280℃. 5 sec.
Storage Conditions:+10℃ to +60℃
Relative humidity:≤75% yearly average Without dew, maximum 30 days at 95%
