Suitable for 250VAC or less than 250VAC voltage circuits, mainly used in home appliances, consumer electronics, adapters, PC power supplies and other computer peripheral products
Time-Current characteristic: Time-Lag(T)
Breaking Capacity: 200A@250VAC,400A@125VAC,1500A@250VAC,10KA@125VAC
Standard: IEC 60127-2/V
Approvals: cURus、VDE、CQC、TUV、PSE、CCC、KC、BSI、SEMKO
Material: Tube- ceramic, metal caps- nickel coated copper, lead cap-nickel plated cap, tinned copper wire
Operation Temperature: -55℃ ~ +125℃
Weldability: 260℃≤5 seconds(wave-soldering), 350℃≤3 seconds(hand welding)
Soldering Peak: 260℃, 10 seconds, /280℃, 5 seconds
Storage conditions: +10℃ ~ +60℃,average annual relative humidity ≤75%,dry maximum value of 30 days is 95%
