Suitable for 250VAC or less than 250VAC voltage circuits, mainly used in home appliances, consumer electronics, adapters, PC power supplies and other computer peripheral products
Time-Current characteristic: Fast-Acting(F)
Breaking Capacity: 100A@250VAC,10KA@125VAC
Standard: IEC 60127-2/II
Approvals: cURus、CQC、VDE、PSE、CCC
Material: Tube- glass, metal caps- nickel coated copper, lead cap- nickel-plating, tin-plating copper
Operation Temperature: -55℃ ~ +125℃
Weldability: 260℃≤5 seconds(wave-soldering), 350℃≤3 seconds(hand welding)
Soldering Peak: 260℃, 10 seconds, /280℃, 5 seconds
Storage conditions: +10℃ ~ +60℃,average annual relative humidity ≤75%,dry maximum value of 30 days is 95%
